Detecting Datacenter and Residential Proxies

In the following blog article, I assume that we are running a web server that hosts a web page and our task is to detect with sufficient accuracy that this site's visitor is using a proxy to hide it's true source IP address.

Graphically:

[browser/client] ---> [http/socks proxy] ---> [target website]

First I need to define what a proxy is: A proxy is any kind of intermediate host to which you can send your network packets in order to camouflage your true source IP address. Proxies are often used for web scraping, because when you request a website too frequently with the same IP address, you will get blocked based on your IP address access count. Therefore, switching IP addresses by using several different proxies is way to evade this kind of block.

For stupid people (such as me), the Internet basically runs on top of two protocols:

1. The IP protocol - this is the protocol that handles packet routing on a hop to hop basis
2. The TCP protocol - TCP assumes that some kind of connection exists. It takes for granted that there is a connection from host A to host B. It then handles things such as reliability, congestion control and transmission loss so that applications can communicate without worrying about such things...

Put differently, IP handles all the little annoying details such as: How is my packet properly routed from my Laptop's network card to the my home modem/router, how does the modem send the network packet to the ISP's infrastructure. How does the ISP route the IP packet to the next host? And so on.

For example, the routing path obtained with tracepath from my home in Germany to my webserver (also in Germany) looks like the following:

$ tracepath incolumitas.com
 1?: [LOCALHOST]                      pmtu 1500
 1:  _gateway                                              1.640ms
 1:  fritz.box                                             1.241ms
 2:  192.0.0.2                                             1.382ms pmtu 1452
 2:  192.0.0.1                                             6.680ms
 3:  62.214.39.53                                          7.620ms
 4:  62.214.37.202                                        17.278ms asymm  5
 5:  et-0-0-2.ams3-edge1.digitalocean.com                 15.166ms
 6:  138.197.244.86                                       28.158ms
 7:  138.197.250.142                                      22.939ms asymm  6
 8:  no reply
 9:  no reply
10:  167.99.241.135                                       20.330ms reached
     Resume: pmtu 1452 hops 10 back 9

However, we cannot take for granted that the above routing information is correct. Path discovery is often done with ICMP and routers can silently drop ICMP packages. Nobody can force any host on the IP packets path to reply (correctly).

The only thing that we are able to see is the external IP address of the incoming IP packet. We don't know if this is the host that is also the originator (in terms of the process that sent the packet on it's way) of the packet or if it is just a proxy.

The real source is the process the creates the socket and sends the TCP/IP packets on their merry way. The real source is the machine that orchestrates and handles the application level logic.

In the remainder of this blog post I will investigate several ideas how to reveal that a visitor requested my web site through a proxy.

First Idea: Cross Ping

This is not my idea. After visiting whatleaks.com/, I saw that they have a ping test that is capable of detecting whether a proxy/tunnel is used. The idea is straightforward:

We compare ping from your computer to our server and ping from our server to the host of your external IP. If the difference is too much then there is probably a tunnel and you are using a proxy.

Put differently, the idea is the following:

If there is no intermediate proxy server used, the ping time from computer (browser) to server should be the same as from server to the external IP address. But if there is a proxy server in the middle, then the ping time from server to external IP address should be significantly faster than from computer (browser) to server. We can repeat the pings in order to cancel out statistical deviations.

That sounds easy, but in reality we will face several issues:

1. Ping uses the ICMP protocol. The ICMP packet is encapsulated in an IPv4 packet. The packet consists of header and data sections. ICMP is a thin protocol that builds on top of the IP protocol. We can easily use the ping command line utility on the server side, but not from the web browser where all we have is JavaScript. It's really not easy to implement something like ping with JavaScript.
2. When we ping the external IP address (that is assumed to either be the proxy server or the source host), we sometimes don't get an answer. The proxy server can choose to not respond to ICMP packets. However, if it is a proxy server, then a port scan must reveal at least one open TCP/IP port.

The ping on the server side is easy to implement:

app.get('/ping', async (req, res) => {
  // ping the external IP address
  let ip = getIp(req);

  let command = `timeout 0.75 ping -qc1 ${ip} 2>&1 | awk -F'/' 'END{ print (/^rtt/? "OK "$5" ms":"FAIL") }'`;
  const { stdout, stderr } = await exec(command);

  res.header("Content-Type",'application/json');
  return res.send(JSON.stringify(stdout.trim(), null, 2));
});

The ping on the JavaScript side is if course a bit tougher. We can't sent ICMP messages, so we have to make use of what is available.

Of course it's also thinkable to compute the latency with through other side channels such as DNS queries, WebSocket messages or even webRTC.

But in the following solution, we will create an <img> element with an invalid src attribute and use it to estimate the RTT to the webserver. Please keep in mind that while we have a one way latency with ping, with JavaScript there is at least a TCP handshake involved and we talk about RTTs.

function ping(url) {
  var started = new Date().getTime();
  var started2 = performance.now();
  var http = new XMLHttpRequest();

  var cacheBuster = '?bust=' + (new Date()).getTime()
  url += cacheBuster;

  http.open("GET", url, /*async*/true);
  http.onreadystatechange = function() {
    if (http.readyState == 4) {
      var ended = new Date().getTime();
      var ended2 = performance.now();

      var milliseconds = ended - started;
      console.log("Took ms: ", milliseconds, ended2 - started2);
    }
  };
  try {
    http.send(null);
  } catch(exception) {
    // this is expected
  }
}

ping("https://incolumitas.com")

It's slightly pedantic to also use performance.now() to measure the RTT, but I want to get extra sure that new Date() is not accurate enough. For our use case, the Same Origin Policy does not prevent us from measuring the latency from browser -> server, because we want to measure the latency to our own origin (our own server).

The lines

var cacheBuster = '?bust=' + (new Date()).getTime()
url += cacheBuster;

prevent the browser from caching the images and thus giving false results for latency measurements.

Live Example and Explanation of Results

You can also visit the example page here: https://bot.incolumitas.com/crossping.html

Keep in mind though: When you visit the example page with your normal browser that is not behind a proxy, your result will look something like this:

On the other hand, when a browser hides behind a proxy server, you will obtain a result as below. As an example, I used a well known scraping service and tested their JavaScript capable bot with the live testing site.

And another example for a scraping service's bot that hides behind a proxy:

We can make two key observations:

1. Normal users have browser -> server JavaScript ping latencies in the range of roughly 100ms to 500ms. But when you hide behind a proxy, this number grows significantly to the range 1500ms - 6000ms.
2. The ping latency from server -> external IP address can either not be obtained (because normal computers behind a NAT/CGNAT are not pingable), or the ping latencies are relatively low in case of proxy servers with a range 20ms - 200ms.

From this follows that we need to make an estimate what latencies are considered normal and what latencies are high enough to be considered as the result of an intermediate proxy server.

Improving RTT measurement server -> external IP

Instead of measuring the latency with ping from server -> external IP address, it is probably a better idea to take the RTT measurements from the initial TCP handshake of the incoming connection. There we can at least take an accurate measurement on the server.

Another advantage is that we don't have the problem of not pingable hosts. Also: The RTT is much easier to compare to the above JavaScript ping implementation than the ping one way latency.

Second Idea: WebRTC Leaks the true IP Address

This is a older technique, but still very relevant.

WebRTC (Web Real-Time Communication) is a technique that allows direct peer-to-peer communication in browseres. It is intended to make direct audio and video communication between peers possible.

Because direct peer to peer communication is possible, there must be a way to detect the public and internal IP addresses of the peers. This is made possible with a so called STUN protocol.

Session Traversal Utilities for NAT (STUN) (acronym within an acronym) is a protocol to discover your public address and determine any restrictions in your router that would prevent a direct connection with a peer. The client will send a request to a STUN server on the Internet who will reply with the client’s public address and whether or not the client is accessible behind the router’s NAT. (Source)

However, the WebRTC protocol is unaffected by the proxy settings. If a browser is configured to use a proxy server, WebRTC does not communicate through this proxy.

This allows us to detect the real IP address of a browser that uses otherwise a proxy.

WebRTC JavaScript Detection Implementation

Visit the demo site.

The following JavaScript Source demonstrates the technique:

<!DOCTYPE html><html>
<head>
  <meta charset="utf-8">
  <meta name="viewport" content="width=device-width, initial-scale=1">
  <title>WebRTC leak</title>
</head>
<body>
  <script>
    var ips = [];

    function findIP() {
      var myPeerConnection = window.RTCPeerConnection || window.mozRTCPeerConnection || window.webkitRTCPeerConnection;
      var pc = new myPeerConnection({iceServers: [{urls: "stun:stun.l.google.com:19302"}]}),
        noop = function() {},
        localIPs = {},
        ipRegex = /([0-9]{1,3}(\.[0-9]{1,3}){3}|[a-f0-9]{1,4}(:[a-f0-9]{1,4}){7})/g,
        key;

      function ipIterate(ip) {
        if (!localIPs[ip]) {
          ips.push(ip);
          document.getElementById("webRTCResult").innerHTML = JSON.stringify(ips, null, 2);
        }
        localIPs[ip] = true;
      }

      pc.createDataChannel("");

      pc.createOffer(function(sdp) {
        sdp.sdp.split('\n').forEach(function(line) {
          if (line.indexOf('candidate') < 0) return;
          line.match(ipRegex).forEach(ipIterate);
        });
        pc.setLocalDescription(sdp, noop, noop);
      }, noop);

      pc.onicecandidate = function(ice) {
        if (!ice || !ice.candidate || !ice.candidate.candidate || !ice.candidate.candidate.match(ipRegex)) return;
        ice.candidate.candidate.match(ipRegex).forEach(ipIterate);
      };
    }

    try {
      findIP();
    } catch(err) {
      ips = 'WebRTC failed: ' + err.toString();
      document.getElementById("webRTCResult").innerHTML = JSON.stringify(ips, null, 2);
    }
  </script>

  <h4>WebRTC Detected IPs</h4>
  <pre id="webRTCResult"></pre>
</body>
</html>
